Hi everyone,
There are a lot of people who ask what’s the best way to get multiple copies of their image backup. There has been instances where manually copying the image backup has resulted in restore failures. Some had observed this as a security feature implemented by Windows so that the backup could only be restored with the original destination.
There were other instances where people said that they’d had no such bad experience and were able to restore from a backup which was copied across to another device.
I hadn’t personally seen this work ever – it was just word of mouth from various sources. I wanted to see this for myself and thought that some people may benefit also.
The Test
The following was produced by following the premise below:
- The WindowsImageBackup folder (and sub-directories) was copied from one USB hard drive (USB A) to another USB hard drive (USB B) through Windows Explorer.
- The backup on USB A was successfully restored before this to make sure the backup was restorable.
- All recoveries performed were Bare Metal Recoveries.
- Dissimilar hardware tests involved the backup of a machine running an Intel Core 2 Quad Q6600 CPU 2.40GHz. The restoration was performed on a machine running an AMD Athlon II 170u CPU 2GHz.
| Operating System |
Similar Hardware |
Dissimilar Hardware |
| Server 2008 (SP1 installed) |
 |
 |
| Server 2008 (SP2 installed) |
 |
 |
| Server 2008 R2 |
 |
 |
With the Server 2008 (SP1 & SP2) tests, both were able to detect the backup on USB B but when it came to restoring the backup they received Error Details: Element Not Found (0×80070490). It appears that the reason for this is that a unique hardware identifier of USB A is referenced and when restoring from USB B, the identifier doesn’t match causing the failure.
Upon doing some further research, it sounds as if a lot of people have had this exact issue in live situations; however I wasn’t able to find any of them giving a resolution or work around.
When performing the restore of Server 2008 R2 to dissimilar hardware, initially the restore was successful although the system would not boot; just open Complete PC Restore and once complete; reboot again. I was required to run a registry fix using RecoverAssist; which is a recovery tool which comes packaged with BackupAssist v6.4 onward. More about RecoverAssist can be found here.
Summary
If you’re running a Server 2008 R2 generation operating system (Server 2008 R2, SBS 2011, etc.) then it is possible to copy your image backup to different devices and not cause any restoration doubts.
When running Server 2008 generation operating systems (Server 2008, SBS 2008, etc.); it’s highly recommended that you create a new backup on each device using BackupAssist instead of making manual copies. This will most likely avoid some heartache in the event that you’re required to perform a Bare Metal Recovery of your data.
If you have any feedback/personal experiences/questions regarding this (especially if you’ve found a way to restore using first generation Server 2008 operating systems), please contact us by e-mailing support@backupassist.com.
Kind Regards,
Stuart
BackupAssist Support Team
